4-20MA actuator position control
4-20mA real time feedback of actuator position
SW1 switch quantity forced action function: can be forced to fully open, forcibly close, and forcibly open to a custom position (LCD screen setting)
With full open and full close limit feedback
Adopting a 1.3-inch OLED large screen LCD with no visual angle limitation, high brightness, energy saving and environmental protection, real-time display of valve opening and feedback
Switch to manual control mode and set the opening through the LCD screen
In the power off state, the opening of the actuator can be manually adjusted using an inner hexagon spanner
The actuator position can be set when there is no control signal: fully open, fully closed, held, custom position
Customizable actuator switch speed, 10 to 30 seconds (slower speed, lower torque)
Customizable control accuracy, with a maximum accuracy of 0.8%. The higher the accuracy, the more accurate it can be; the lower the accuracy, the lower the frequency of valve action, and the longer the service life
High performance brushless motor with built-in overheating/overload protection
Built in motor control module, capable of variable frequency speed control of the motor, achieving precise positioning and stepless speed regulation
Real time prompt of fault menu (including faults caused by actuator jamming or other reasons causing actuator switch not in place)
The system can restore factory settings through button operation
