Designed for high temperature flue gas make-up heat with low oxygen content
200kW/PCS in single module combustion mode
Modular design for a variety of combinations
Greatly improved flue gas heating uniformity
Maximum flame length up to 3 metres
Burner modulation ratio up to 10:1
Low CO and NOx emissions
No combustion fan required
Application
The Flubfire burner is designed to be modular in order to meet the diversity of the user's installation, and can be assembled into rectangular, round, T-shaped and other forms through the different combinations of the modules.The Flubfire burner modules are made of high-temperature-resistant stainless steel, and the temperature of the flue gas upstream can reach 600°C, and the downstream flue gas can reach 1,000°C. Particularly in the case where the oxygen content is lower than that required by the burner standard, it is extremely easy to add a fresh air device at the rear of the module to increase the oxygen content. Especially when the oxygen content is below the standard requirements of the burner, it is extremely easy to add fresh air to the rear of the module to increase the oxygen content.
